Specifications
Real time
DPX minimum sig
nal duration
(100% POI)
100 s
DPX settings: Span = 40 MHz, R BW = 300 kHz (Auto)
Due to the nondeterministic execution time of programs running under Microsoft
Windows OS, th
is specification may not be met when the host PC is heavily loaded
with other processing tasks
DPX b itmap im
age resolution
201 pixels ve
rtical x 801 pixels horizontal
DPX spectrogram minimum time
resolution
1 millisecond
Due to the non
-deterministic execution time of programs running under Microsoft
Windows OS, this specification may not be met when the host PC is heavily loaded
with other processing tasks
Audio demodulation
Types AM, FM
IF bandwidth range Five selections, 8 kHz – 200 kHz
Audio output frequency range
50Hz–10kHz
Interfaces, input, output ports
RF input
Type N, female
External frequency reference
input
SMA, female
Trigger/sync input SMA, female
Status indicator LED, dual color red/green
LED states:
Steady Red: USB power applied
, or resetting
Steady Green: Initialized, ready for use
Flickering Green: Transferring acquired data to host PC
USB device port USB 3.0 - Micro-B (with thumbscrews on instruments serial numbered B010900
or above)
Power
Power c on sumption
Per USB 3.0 S uperSpeed requirements: 5.0 V, 900 mA, nominal
Physical
Weight
0.59 kg (1.3 lbs)
Dimensions
Height
30.5 mm (1.2 in)
Width
127 mm (5.0 in)
Depth
190.5 mm (7.5 in)
RSA306 Specifications and Performance Verification 8
