Tektronix RSA306 Technical Reference

Specifications
2
ND
harmonic distortion, typical
< –55 dBc, 10 MH
z to 300 MHz, reference level = 0 dBm
< –60 dBc, 300 MHz to 3.1 GHz, reference level = 0 dBm
< –50 dBc, 10 MHz to 1850 MHz, and 2330 MHz to 3100 MHz, reference level =
–40 dBm
< –45 dBc , 1850 MHz to 2330 MHz, reference level = –40 dBm
2
ND
harmonic
distortion
intercept (SHI), typical
+55 dBm, 10 M Hz to 300 MHz, reference level = 0 dBm
+60 dBm, 300 MHz to 3.1 GHz, reference level = 0 dBm
+10 dBm, 10 M
Hz to 1850 MHz, and 2330 MHz to 3100 MHz, reference level =
–40 dBm
+5 dBm, 1850 MHz to 2330 MHz, reference level = –40 dBm
Local oscillato r feedthrough to
input con n
ector, typical
< –75 dBm
Reference level = –30 dBm
Table 1: F
requency Tuning Table, RF Signal Path gain cal version 1 or greater, software REV. 3.5.0134 or
greater
Sub-
band
Pre-
Selec-
tor Fil-
ter
Cen-
ter
Freq.
Min.
(MHz)
Cen-
ter
Freq.
Max
(MHz)
LO1
Min
(MHz)
LO1
Max
(MHz)
IF1
(MHz)
LO1
High
/Low
Side
m
(RF) n (LO)
LO2
(MHz)
0 LF 0.009 22 None None
DC
111None
1 1 22 700 2462 3140 2440 1 –1 1 2300
2 2 700 1850 3140 4290 2440 1 –1 1 2300
3 3 1850 2700 3040 3890 1190 1 –1 1 1050
4 4 2700 3100 3890 4290 1190 1 –1 1 1050
5
4 3100 3700 4290 4890 1190 1 –1 1 1050
6
5
3700 4175 4890 5365 1190 1 –1 1 1050
75
4175 4225 1735 1785 2440 –1 1 –1 2300
8
5
4225 4750 5415 5940 1190 1 –1 1 1050
9
5
475
0
496
0
356
0
377
0
119
0
–1 1 –1 105
0
10 6 4960 5100 3770 3910 1190 –1 1 –1 1050
11 6 5100 5695 3910 4505 1190 –1 1 –1 1050
12 6 56
95
57
00
45
05
45
10
11
90
–1 1 –1 10
50
13
7
5700 5900 4510 4710 1190 –1 1 –1 1050
14
7
5900 6220 4710 5030 1190 –1 1 –1 1050
7 RSA306 Specifications and Performance Verification
