Table 6: Amplitude accuracy, 0 dBm reference level measurements (cont.)
Center/signal
frequency
RSA306 reading,
dBm
Power meter value,
dBm
Error (RSA306 –
Pwr meter), dB
100 kHz
300 kHz
1MHz
3MHz
10 MHz
20 MHz
22 MHz
100 MHz
699 MHz
701 MHz
1GHz
1.849 GHz
1.851 GHz
2.339 GHz
2.341 GHz
2.419 GHz
2.421 GHz
2.699 GHz
2.701 GHz
3.000 GHz
3.699 GHz
3.701 GHz
4.569 GHz
4.571 GHz
4.629 GHz
4.631 GHz
4.749 GHz
4.751 GHz
4.959 GHz
4.961 GHz
5.699 GHz
5.701 GHz
