Tektronix RSA306 Technical Reference

Performance ver
ification
Table 8: Amplitude accuracy, –30 dBm reference level measurements (cont.)
Center/signal
frequency
RSA306 reading,
dBm
Power meter value,
dBm
Error (RSA306 –
Pwr meter), dB
2.341 GHz
2.419 GHz
2.421 GHz
2.699 GHz
2.701 GHz
3.000 GHz
3.699 GHz
3.701 GHz
4.569 GHz
4.571 GHz
4.629 GHz
4.631 GHz
4.749 GHz
4.751 GHz
4.959 GHz
4.961 GHz
5.699 GHz
5.701 GHz
5.804 GHz
5.806 GHz
6.200 GHz
Table 9: Amplitude accuracy results
Reference level
Frequency
range
Maximum
+error
Maximum
–error Specification
9kHzto
2.701 GHz
±2.0 dB+20 dBm
3GHzto6.2GHz
±2.75 dB
9kHzto
2.701 GHz
±2.0 dB0 dBm
3GHzto6.2GHz
±2.75 dB
9kHzto
2.701 GHz
±2.0 dB-13 dBm
3GHzto6.2GHz
±2.75 dB
RSA306 Specifications and Performance Verification 22
