Tektronix RSA306 - Page 38

Performance ver
ification
Table 11: 1280 MHz channel flatness, 1260 MHz – 1300 MHz
Signal
generator
frequency
Power meter
amplitude, dB
RSA306 marker
amplitude, dB
Difference
amplitude, dB
m
Channel
flatness error,
dB
1260 MHz
1262 MHz
1264 MHz
1266 MHz
1268 MHz
1270 MHz
1272 MHz
1274 MHz
1276 MHz
1278 MHz
1280 MHz
1282 MHz
1284 MHz
1286 MHz
1288 MH
z
1290 MHz
1292 MHz
1294 M
Hz
1296 MHz
1298 MHz
1300
MHz
Maximum difference amplitude
<+1dB
Minimum difference amplitude
>–1
dB
27 RSA306 Speci fications and Performance Verification
