Performance ver
ification
8. Calculate and record IMD (dBc):
(maximum of IMD #1 or IMD #2) +20 dBm = IMD (dBc)
9. Record the result in the Test record.
Table 15: Third order intermodulation distortion measurements
Item Measurement Specificatio
n
Carrier #1 amplitude
–20 dBm
Carrier #2 amplitude
–20 dBm
IMD #1 ampl
itude
< –80 dBm typ.
IMD #2 amplitude
< –80 dBm typ.
IMD
(Max IMD – (–20 dBm))
< –60 dBc
35 RSA306 Speci fications and Performance Verification
