Tektronix RSA5106B Technical Reference

Specifications
Table 5: RF input (cont.)
Characteristic Description
RSA5115B >10 MHz to 15 GHz
<1.9
>10MHzto6.2GHz
<1.9
>6.2 GHz to 11 GHz
<2.25
>11 GHz to 25 GHz
<1.9
RSA5126B
>25GHzto26.5GHz
<12.1
Table 6: Maximum input level
Characteristic Description
Maximum DC voltage ±5 V (RF Input)
Maximum safe input power +30 dBm (RF Input, RF ATT 10 dB, Preamp Off)
+20 dB
m (RF Input, RF ATT 10 dB, Preamp On)
+50 Watts peak (RF Input, RF ATT 30 dB (<10 s Pulse Width, 1% Duty Cycle
repetitive Pulses)
Maximum Measurable input power
+30 dBm (RF Input, RF ATT Auto)
+10 W
atts peak (RF Input, RF ATT Auto), (<10 s Pulse Width, 1% Duty Cycle
repetitive pulses)
Table 7: Input attenuator
Characteristic Description
RF Attenuator (DC to 26.5 GHz) 0 dB to 55 dB (5 dB step), nominal
6 RSA5100B Series Technical Reference
