Tektronix RSA5106B Technical Reference

Specifications
Table 14: Chann
el response after cal/norm (center frequency 2 00 MHz)
1
Characteristic Description
Amplitude Fla
tness
Specification
BW 300 kHz ±0.10 dB
BW 300 kHz,
CF > 0.01 GHz
2
±0.20 dB
BW 10 MHz, C
F > 25/40 MHz
±0.40 dB
BW 40 MHz,
CF > 85 MHz
±0.50 dB
BW 85 MHz,
CF > 110 MHz
±0.50 dB
BW 110 MH
z, CF > 125 MHz
±0.50 dB
BW 125 M
Hz, CF > 160 MHz
±0.50 dB
Phase Linearity, typical
BW 300 kHz
±0.1 °
BW 300 kHz, C F > 0.01 GHz
2
±0.5 °
BW 10 MHz, CF > 25/40 MHz ±0.75 °
BW 40 MHz, CF > 85 MHz ±2 °
BW 85 MHz, CF > 110 MHz ±2 °
BW 110 MHz, CF > 125 MHz ±2 °
BW 125 MHz, CF > 160 MHz ±2 °
1
The BW value used in this table is the bandwidth of the channel. Atten = 10 dB. Use Flattop Window for maximum CW amplitude verification accuracy.
2
High Dynamic Range mode.
Table 15: Channel response after cal/norm (>6.2 GHz < center frequency ≤15/26 GHz) (RSA5115B/5126B)
1
Characteristic Description
Amplitude Flatness
Specification
Typical
BW 300 kHz
2
±0.1 dB 0.05 dB
RMS
BW 25/40 MHz
±0.5 dB 0.40 dB
RMS
BW 80 MHz ±0.75 dB 0.7 dB
RMS
BW 110 MHz
3
±1.0 dB 0.7 dB
RMS
BW 125 MHz
3
±1.0 dB 0.7 dB
RMS
BW 165 MHz
3
±1.0 dB 0.7 dB
RMS
Phase Linearity, typical
BW 300 kHz
2
0.2 °
RMS
BW 25/40 MHz 1.0 °
RMS
BW 80 MHz
1.5 °
RMS
BW 110 MHz
4
1.5 °
RMS
BW 125 MHz
4
1.5 °
RMS
BW 165 MHz
3
1.5 °
RMS
1
The BW value used in this table is the bandwidth of the channel. Atten = 10 dB. Use Flattop Window for maximum CW amplitude verification accuracy.
2
High Dynamic Range mode.
16 RSA5100B Series Technical Reference
