Specifications
Table 26: Acquisition (cont.)
Characteristic Description
Acquisition Length Setting resolution in
RTSA/Time/Demod Mode, nominal
1sample
Acq BW > 2.5 MHz (1 GB)
(Std)
256 MSamples
Acq BW  2.5 MHz (1 GB)
(Std)
128 MSamples
Acq BW > 2.5 MHz (4 GB)
(Option 53)
1GSamples
Acquisition
Memory Size
Acq BW  2.5 MHz (4 GB)
(Option 53)
512 MSamples
Table 2
7: Amplitude vs. time
Characteristic Description
Time Scale (Zero Span), nominal 400 ns min to 2000 s max (Option B16x)
1 s min to 2000 s max (Standard)
Time Accuracy
±0.5% of total time
Time Resolution
0.1% of total time
Time Linearity
±0.5% of total time (measured at 11 equally-spaced points across the display,
inc
luding the ends)
30 RSA5100B Series Technical Reference
