Specifications
Safety
For detailed information on Safety, see the RSA5100B Series Real-Time Signal
Analyzers Quick Start User Manual, Tektronix part number 071-3224-XX.
Certifications and Compliances
For detailed information on Certifications and Compliances, see the RSA5100B
Series Rea
l-Time Signal Analyzers Quick Start User Manual, Tektronix part
number 071-3224-XX.
Environmental Characteristics
Table 63: Environmental characteristics
Characteristic Description
Temperature range
1
Operating +5 °C to + 40 °C
Non-operating
–20 °C to +60 °C
Relative Humidity
+40°C at 95% relative humidity, meets intent of EN 60068-2-30
Frequency a mplitude response may vary up to ±3 dB at +40 °C and greater than
45% relative humidity.
Altitude
Operating Up to 3000 m (approximately 10000 ft)
Non-operating
Up to 12190 m (40000 ft)
Vibration
Operating 0.22 G rms. Profile = 0.00010 g
2
/Hz a t 5 Hz to 350 Hz, –3 dB/Octave slope from
350 Hz to 500 Hz, 0.00007 g
2
/Hz at 500 Hz, 3 Axes at 10 min/axis, Class 8. Electrical
Specifications defined in sections above are not warranted under the operating
vibration conditions.
Non-operating
2.28 G rms. Profile = 0.0175 g
2
/Hz at 5 Hz to 100 Hz, –3 dB/Octave slope from
100 Hz to 200 Hz, 0.00875 g
2
/Hz at 200 Hz to 350 Hz, –3 dB/Octave slope from
350 Hz to 500 Hz, 0.00613 g
2
/Hz at 500 Hz, 3 Axes at 10 min/axis. Class 5
Shock
Operating (15 G), half-sine, 11 ms duration.
Three s hocks per axis in each direction (18 shocks total)
Non-operating
296 m/s
2
(30 G), half-sine, 11 ms duration.
Three s hocks per axis in each direction (18 shocks total)
RSA5100B Series Technical Reference 63
