Specifications
Table 19: Test P
arameters for Pulse to Pulse Carrier Phase/Frequency
Acquisition BW
(MHz)
Gaussian Filter BW
(MHz)
IQ Samplin g Rate
(MHz)
Min Pulse Length
(ns)
Min Measurement
Timing from Rising
Edge (ns)
Std/Option B40
20 10 25 3000 1000
Std/Option B40
25 12.5 50 3000 1000
Option B85
60 30
75
1500 500
Option B85
85 42.5 150 750 250
Option B125
125 62.5 200 750 250
Option B1
6x
160 80 200 600 200
Table 20: Spurious response
Characteristic Description
200 MHz to 3 GHz
<–95 dBm
3 GHz to 6.2 GHz (RSA5106B)
<–95 dB
m
6.2 GHz to 15 GHz (RSA5115B)
<–95 dBm
15 GHz to 26.5 GHz (RSA5126B)
<–95 dBm
500 kHz to 32 MHz, LF Band <–100 dBm, typical
500 kHz to 80 MHz, RF band
(RSA5103B/5106B)
<–75 dBm, typical
1 MHz to 80 MHz, RF band
(RSA5115B/5126B)
<–75 dBm, typical
Residual Response (Atten = 0 dB , Ref =
–30 dBm, RBW = 1 kHz)
80 MHz to 200 MHz, RF band <–95 dBm, typical
Residual DC Offset after Normalization (LF
Path), typical
<-40 dBm (Ref level 0 dBm)
<-40 dBm from Ref level (Ref level
> 0 dBm)
<–75 dBc (10 kHz to < 30 MHz, Ref= –30 dBm, Atten = 10 dB, RF Input Level =
–30 dBm, RBW = 10 Hz) LF path
<–75 dBc (30 MHz to < 3 GHz, Ref= –30 dBm, Atten = 10 dB, RF Input Level =
–30 dBm, RB W = 10 Hz)
<–70 dBc (3 GHz to 6.2 GHz, Ref= –30 dBm, Atten = 10 dB, RF Input Level =
–30 dBm, RBW = 10 Hz) (RSA5106B)
<–76 dBc (6.2 GHz to 15 GHz, R ef= –30 dBm, Atten = 10 dB, RF Input Level =
–30 dBm, RBW = 10 H z) (RSA5115B)
<–72 dBc (15 GHz to 26.5 GHz, Ref= –30 dBm, Atten = 10 dB, RF Input Level =
–30 dBm, RBW = 10 Hz) (RSA5126B)
Spur
ious Response with Signal (Image
Suppression)
Equal or better performance is expected when Preamp is turned on and the power
level at the output of RF attenuator is lower or equal than –55 dBm.
Higher RF Order Spurious Response w/
Signal at other than Center Frequency
(6.2 GHz to 26.5 GHz)
Span 25 MHz, swept spans >25 MHz,
typical
For Options B40/B85/B16x, 25 MHz <
Span 160 MHz, typical
RSA5100B Series Technical Reference 25
