Tektronix RSA5106B Technical Reference

Specifications
Table 28: Trigger (cont.)
Characteristic Description
Standard:
±13 s at 25 MHz span for base unit (Standard) RBW 300 kHz
±13 s at 40 MHz span (Option B40), RBW 300 kHz
±10 s at 85 MHz span (Option B85), RBW 1MHz
±10 s at 125 MHz span (Option B125) RBW 1MHz
±9 s at 165 MHz span (Option B16x), RBW 1MHz
Option 09:
±7 s at 25 MHz span for base unit (Standard) RBW 300 kHz
±6 s at 40 MHz span (Option B40), RBW 300 kHz
±3 s at 85 MHz span (Option B85), RBW 1MHz
±3 s at 125 MHz span (Option B125), RBW 1MHz
±3 s at 165 MHz span (Option B16x), RBW 1MHz
Frequency Mask Trigger Timing
Uncertainty
Instrument Center Frequency 100 MHz
Runt Trigger Level Range, nominal
Same as Power Trigger Level Range
Runt Trigger Level Resolution,
nominal
Same as Power Trigger Level Resolution
Runt Trigger Polarity, nominal
POSitive
NEGative
Runt Trigger Level Accuracy
Same as Power Trigger Level Accuracy
This applies when the R unt Trigger Level is between 10% and 90% of the signal amplitude.
Runt Trigger Position Timing
Uncertainty
Same as Power Trigger Position Timing Uncertainty
DPX Statistics Trigger Minimum
Detectable Trigger Event Duration,
typical
Same as DPX Min Signal Duration for 100% probability of intercept
DPX Statistics Trigger Threshold
Setting Range, nominal
0% – 100%
DPX Statistics Trigger Area of
Interest Range, nominal
2 to 801 pixels (horizontal) x 2 to 201 pixels (vertical)
DPX Statistics Trigger Area of
Interest Re solution, nominal
1 pixel, horizontal or vertical
DPX Statistics Trigger Area of
Interest Accuracy, nominal
Horizontal: ±0.25% of Span
Vertical: ±(2 X DPX amplitude accuracy)
RSA5100B Series Technical Reference 35
