Speciﬁcations

Table 28: Trigger (cont.)

Characteristic Description

For Power Trigger:

±[(2 X Power Trigger Position Timing Uncertainty) + 5 ns];

All conditions for Power Trigger Position timing uncertainty must be met

For FMT:

±[(2 X Frequency Mask Timing Uncertainty) + 5 ns];

All conditions for Frequency Mask Trigger timing uncertainty must be met

For DPX Density Trigger:

±50 ms;

For External Trigger SPAN  40 MHz:

±[(2 X External Trigger Timing Uncertainty) + 20 ns];

All conditions for External Trigger Timing uncertainty must be met

For External Trigger 40 MHz < SPAN  165 MHz:

±[(2 X External Trigger Timing Uncertainty) + 5 ns];

All conditions for External Trigger Timing uncertainty must be met

Time Qualiﬁed Trigger (minimum or

maximum) Time Accuracy, nominal

Instrument Center Frequency 100 MHz

Holdoff Trigger ON or OFF

Reference Information: Holdoff Trigger means triggers will be held off until a period of time

equal to or greater than the Holdoff Trigger Time occurs with no trigger events; once the

Holdoff timer has expired, a trigger will be generated on the next trigger event

Holdoff Trigger Source Applied to any allowed combination of trigger source and time qualiﬁcation

Holdoff Trigger Time Range, nominal

20 ns to 10 s

Holdoff Trigger Time Resolution,

nominal

Trigger Source is not EXTERNAL: 5 ns

Trigger S ource is EXTERNAL:

SPAN 40 MHz: 20 ns

40 MHz < SPAN  165 MHz: 5 ns

RSA5100B Series Technical Reference 37
