Performance Verification
Table 70: Equipment required for Performance Verifi cation (cont.)
Item num ber and Minimum requirements Example Purpose
Output Frequency 10 MHz to 26.5 GHz
Phase Noise at Center Frequency = 1 GHz
6. RF Signal
Generator
Offset
10 Hz
100 Hz
1kHz
10 kHz
100 kHz
1MHz
SSB Phase Noise (F) dBc/Hz
–71
–93
–118
–121
–119
–138
Anritsu MG3694B
Options 2A, 3A, 4, 15A,
16, 22, SM5821
Checking phase
noise and third
order intermodulation
distortion
7. Precision
Attenuator
30 dB
8. Power Splitter
Agilent 11667B Adjusting signal
generator output level
9. Power Combiner
Anritsu 2089-6208-00
Checking
intermodulation
distortion
10. Low Pass Filters
(2)
<3 dB loss DC –3 GHz
>50 dB rejection 4 GHz to 14 GHz
Checking third order
intermodulation
distortion
11. Voltmeter
Capable of measuring 30 VDC Standard Equipment Checking Noise Source
Checking Zero-Span
Output
12. BNC Cable 50 , 36 in. male to male BNC connectors Signal interconnection
13. 3.5 mm -3.5 mm
Cable
50 , 36 in. male to male 3.5 mm connectors Signal interconnection
14. N-SMA Cable 50 , 36 in. male N to male SMA connectors S ignal interconnection
15. Termination,
Precision 50
Impedance: 50 3.5 mm male Signal interconnection
16. N-Female to BN C
male Adapter
Tektronix part number
103-0058-00
N cable to RSA5100B
connections
17. 3.5 m m (F)
to 3.5 mm (F)
coaxial adapter
Tektronix part number
131-8508-00
18. N-3.5mm cable
50 , 36 in. male N to male 3.5 mm connectors
19. N-Male to 3.5 mm
male adapter
20. 3.5 mm
attenuator
3 dB (two required)
Midwest Microwave
ATT-0550-03-35M-02
Checking third order
intermodulation
distortion
72 RSA5100B Series Technical Reference
