Operation
Navigating Displays
The RSA6100A Series and RSA5100A Series analyzers use multiple displays to keep operations simple, and yet provide
advanced functionality w hen needed. Some of the display categories include:
General Signal Viewing displays. These displays show graphs for basic signal parameters such as amplitude, phase,
and frequency plotted against frequency or time. Examples of these displays include: Spectrum, DPX , Spectrogram,
Time Overview, and Phase vs Time.
Analog Modulation. These displays show graphs and measurements for Analog Modulation, Frequency Modulation,
and Phase Modulation.
General Purpose Digital Modulation displays. Available with Option 21, General P u rpose Modulation Analysis .
These displays show the results of demodulating signals and analyzing them in multiple domains. Examples of these
displays include: Constellation, EVM vs Time, Eye, Symbol Table, and Trellis diagrams.
RF Measurements displays. These displays show the results of automated measurements on RF signals. Examples of
these displays include: ACPR, MCPR, Phase Noise, and CCDF.
Pulsed RF displays. Available with Option 20, Advanced Signal Analysis. These displays show the results of advanced
analysis for pulsed RF signals. Examples of these displays include: Pulse Statistics, Pulse Table, and Pulse Trace.
RSA6100A Series & RSA5100A Series Q uick Start User Manual 29
