Module servicing
Modules can be serviced by selecting one of the following three options. Contact
your local Tektronix Service Center or representative for repair assistance.
Module exchange. In some cases, you may exchange your module for a
remanufactured module. These modules cost significantly less than new modules
and meet the same factory specifications. For more information about the module
exchange program, call 1-800-833-9200. Outside North America, contact a
Tektronix sales office or distributor; see the Tektronix Web site (www.tek.com)
for a list of offices.
Module repair and return. You may ship your module to us for repair, after
which we will return it to you.
New modules. You may purchase replacement modules in the same way as other
replacement parts.
Using the replaceable parts list
This section contains a list of the replaceable mechanical and/or electrical
components. Use this list to identify and order replacement parts. The following
table describes each column in the parts list.
Table 3: Parts list column descriptions
Column Column name Description
1 Figure & index number Items in this section are referenced by figure and index numbers to the exploded view
illustrations that follow.
2 Tektronix part number Use this part number when ordering replacement parts from Tektronix.
3 and 4 Serial number Column three indicates the serial number at which the part was first effective. Column
four indicates the serial number at which the part was discontinued. No entry indicates
the part is good for all serial numbers.
5 Qty This indicates the quantity of parts used.
6 Name & description An item name is separated from the description by a colon (:). Because of space
limitations, an item name may sometimes appear as incomplete. Use the U.S. Federal
Catalog handbook H6-1 for further item name identification.
Replaceable parts
22 TBS2000B Series Service Manual
