Tektronix TDS 200-Series Service Manual

Specifications
TDS 200 Series Digital Oscilloscope Service Manual
1–3
Table 1–1: Specifications (cont.)
Vertical
Rise Time at BNC, typical TDS 210 TDS 220 and TDS 224
<5.8 ns <3.5 ns
Peak Detect Response
Captures 50% or greater amplitude of pulses ≥10 ns wide (5 s/div to 5 ms/div) in the center 6 vertical
divisions. The oscilloscope reverts to Sample mode when the sec/div (Horizontal scale) setting is from
2.5 ms/div to 5 ns/div. The Sample mode can still capture 10 ns glitches.
DC Gain Accuracy 2 mV/div to 5 mV/div, +4% for Sample or Average acquisition mode
10 mV/div and larger, +3% for Sample or Average acquisition mode
n DC Measurement Accu-
Measurement Type Accuracy
racy, Average Acquisition
Mode
Average of ≥16 waveforms with vertical position at zero
±(4% × reading + 0.1 div + 1 mV) and either
2 mV/div or 5 mV/div is selected.
±(3% × reading + 0.1 div + 1 mV) and 10 mV/div
or greater is selected.
Average of ≥16 waveforms with vertical position not at
zero
±[3% × (reading + vertical position) + 1% of
vertical position + 0.2 div]
Add 2 mV for settings from 2 mV/div to 200 mV/
div. Add 50 mV for settings from u200 mV/div to
5 V/div.
Delta Volts Measurement
Accuracy, Average Acquisi-
tion Mode
Delta volts between any two averages of ≥16
waveforms acquired under same setup and ambient
conditions
3% of reading + 0.05 div
P2100 passive probe
10X position 1X position
Bandwidth DC to 100 MHz DC to 7 MHz
Attenuation ratio 10:1 1:1
Compensation Range 18 pf-35 pf
All oscilloscopes with 1 M W input
Input resistance
10 M W ± 2% 1MW ± 2%
Input capacitance 14.5 pf-17.5 pf 80 pf-110 pf
Maximum input voltage
300 V
RMS
CAT I or 300 V DC CAT I
300 V
RMS
CAT II or 300 V DC CAT II
100 V
RMS
CAT III or 100 V DC CAT III
150 V
RMS
CAT I or 150 V DC CAT I
150 V
RMS
CAT II or 150 V DC CAT II
100 V
RMS
CAT III or 100 V DC CAT III
Horizontal
Sample Rate Range 50 S/s to 1 GS/s
Waveform Interpolation (sin x)/x
Record Length 2500 samples for each channel
SEC/DIV Range 5 ns/div to 5 s/div, in a 1, 2.5, 5 sequence
n Sample Rate and Delay
Time Accuracy
±100 ppm over any ≥1 ms time interval
