Adjustment Procedures
TDS 200 Series Digital Oscilloscope Service Manual
5–5
Table 5–2:
TDS 210 and TDS 220 Adjustment steps
Step:
Firmware
Below V 2.00
Step
Firmware
V 2.00 and Up
Equipment setup Signal source setting Input
1 1 DC Voltage 1 0.0 V
CH1 & CH2
2 2 DC Voltage 1 –20.0 V
3 3 DC Voltage 1 –2.0 V
4 4 DC Voltage 1 –1.6 V
5 5 DC Voltage 1 –1.2 V
6 6 DC Voltage 1 –0.8 V
7 7 DC Voltage 1 –0.4 V
8 8 DC Voltage 1 –0.32 V
9 9 DC Voltage 1 –0.2 V
10 10 DC Voltage 1 –0.16 V
11 11 DC Voltage 1 –0.08 V
12 12 DC Voltage 1 –0.04 V
13 13 DC Voltage 1 –0.03 V
14 14 DC Voltage 1 –0.02 V
15 15 DC Voltage 1 –0.015 V
16 16 DC Voltage 1 0.015 V
17 17 DC Voltage 1 0.02 V
18 18 DC Voltage 1 0.03 V
19 19 DC Voltage 1 0.04 V
20 20 DC Voltage 1 0.08 V
21 21 DC Voltage 1 0.16 V
22 22 DC Voltage 1 0.2 V
23 23 DC Voltage 1 0.32 V
24 24 DC Voltage 1 0.4 V
25 25 DC Voltage 1 0.8 V
26 26 DC Voltage 1 1.2 V
27 27 DC Voltage 1 1.6 V
28 28 DC Voltage 1 2.0 V
29 29 DC Voltage 1 20.0 V
30 30 DC Voltage 1 0.0 V
31 31 DC Voltage 2 –5.0 V
EXT TRIG
32 32 DC Voltage 2 –1.0 V
33 33 DC Voltage 2 1.0 V
34 34 DC Voltage 2 5.0 V
