Adjustment Procedures
5–6
TDS 200 Series Digital Oscilloscope Service Manual
Table 5–2:
TDS 210 and TDS 220 Adjustment steps (cont.)
Step:
Firmware
Below V 2.00
InputSignal source settingEquipment setup
Step
Firmware
V 2.00 and Up
35 35 Sinewave Generator, 50 Ohm 5 kHz, 1 V
p-p
CH1
36 36 Sinewave Generator, 50 Ohm 1 MHz, 1 V
p-p
37 37 Sinewave Generator, 50 Ohm 50 kHz, 1 V
p-p
38 38 Sinewave Generator, 50 Ohm 20 MHz, 1 V
p-p
39 39 Sinewave Generator, 50 Ohm
TDS 210: 60 MHz, 1 V
p-p
TDS 220: 100 MHz, 1 V
p-p
40 40 Sinewave Generator, 50 Ohm 5 kHz, 2.5 V
p-p
41 41 Sinewave Generator, 50 Ohm 1 MHz, 2.5 V
p-p
42 42 Sinewave Generator, 50 Ohm 50 kHz, 2.5 V
p-p
43 43 Sinewave Generator, 50 Ohm 20 MHz, 2.5 V
p-p
44 44 Sinewave Generator, 50 Ohm
TDS 210: 60 MHz, 2.5 V
p-p
TDS 220: 100 MHz, 2.5 V
p-p
45 45 Sinewave Generator, 50 Ohm
TDS 210: 60 MHz, 2.5 V
p-p
TDS 220: 100 MHz, 2.5 V
p-p
None 46 Edge, 50 Ohm 1 kHz, 0 to –800 mV
46 47 Sinewave Generator, 50 Ohm 5 kHz, 1 V
p-p
CH2
47 48 Sinewave Generator, 50 Ohm 1 MHz, 1 V
p-p
48 49 Sinewave Generator, 50 Ohm 50 kHz, 1 V
p-p
49 50 Sinewave Generator, 50 Ohm 20 MHz, 1 V
p-p
50 51 Sinewave Generator, 50 Ohm
TDS 210: 60 MHz, 1 V
p-p
TDS 220: 100 MHz, 1 V
p-p
51 52 Sinewave Generator, 50 Ohm
5 kHz, 2.5 V
p-p
52 53 Sinewave Generator, 50 Ohm 1 MHz, 2.5 V
p-p
53 54 Sinewave Generator, 50 Ohm 50 kHz, 2.5 V
p-p
54 55 Sinewave Generator, 50 Ohm 20 MHz, 2.5 V
p-p
55 56 Sinewave Generator, 50 Ohm
TDS 210: 60 MHz, 2.5 V
p-p
TDS 220: 100 MHz, 2.5 V
p-p
