TDS 200 Series Digital Oscilloscope Service Manual
4–1
Performance Verification
This chapter contains performance verification procedures for the specifications
marked with the n symbol. The following equipment, or a suitable equivalent, is
required to complete these procedures.
Description
Minimum
requirements
Examples
DC Voltage Source 17.5 mV to 7 V, ±0.5%
accuracy
Wavetek 9100 Universal
Calibration System with
Oscilloscope Calibration
Leveled Sine Wave Generator 50 kHz and 100 MHz, ±3%
amplitude accuracy
Oscilloscope Calibration
Module (Option 250)
Fluke 5500A Multi-product
Time Mark Generator 10 ms period, ±25 ppm
accuracy
Calibrator with Oscilloscope
Calibration Option (Option
5500A-SC)
50 W BNC Cable
BNC male to BNC male,
≈ 36 in (1 m) long
Tektronix part number
012-0482-00
50 W BNC Cable
BNC male to BNC male,
≈ 10 in (25 cm) long
Tektronix part number
012-0208-00
50 W Feedthrough Termination
BNC male and female
connectors
Tektronix part number
011-0049-01
Dual Banana to BNC Adapter Banana plugs to BNC female Tektronix part number
103-0090-00
BNC T Adapter BNC male to dual BNC female
connectors
Tektronix part number
103-0030-00
