Maintenance
6–6
TDS 200 Series Digital Oscilloscope Service Manual
You will need the following tools to remove and replace all the modules in the
oscilloscope.
Tools
Torque-limiting screwdriver, 12 in lb (1.3 N
⋅ m) range with Torx T-15 tip
Screwdriver with !@4 inch flat blade
Pliers
Sharp knife (X-ACTO knife or equivalent)
The Mechanical Parts List chapter provides a list of all replaceable modules.
Any electrical or mechanical module, assembly, or part listed in the parts list is
referred to as a module.
