TDS 200-Series Extension Module Instructions
TDS2CM Communications Module
This chapter describes how to set up and test the TDS2CM
Communications Extension Module RS-232 and GPIB interfaces.
The TDS2CM Module includes all features of the TDS2HM Module,
described in TDS2HM Hard Copy Module starting on page 7. This
information also applies to the communications portion of the
TDS2MM Measurement Module.
RS-232 connector
GPIB connector
Centronics connector
