Tektronix TDS 200-Series Instructions

TDS2MM Measurement Module
TDS 200-Series Extension Module Instructions
29
Signal Measurements
Push the MEASURE button to display the automated measurement
menu. The new measurements are in the Type menu. The TDS2MM
Module automatically determines the 10%, 50%, and 90% waveform
points.
Type Definition
Rise Time Measures the time between 10% and 90% of the first
rising edge of the waveform. Rising edge must be
displayed to measure.
Fall Time Measures the time between 90% and 10% of the first
falling edge of the waveform. Falling edge must be
displayed to measure.
Pos Width Measures the time between the first rising edge and the
next falling edge at the waveform 50% level. Rising and
falling edges must be displayed to measure.
Neg Width Measures the time between the first falling edge and the
next rising edge at the waveform 50% level. Falling and
rising edges must be displayed to measure.
