Tektronix TDS 200-Series Instructions

TDS2CM Communications Module
22
TDS 200-Series Extension Module Instructions
GPIB Settings
To set the oscilloscope GPIB interface:
1. If you have not done so yet, connect the oscilloscope to the GPIB
network.
2. On the oscilloscope, push UTILITY
 Options  GPIB Setup.
3. Push the menu button next to the menu item to change the
settings to assign a unique address to the oscilloscope. The
following table lists the settings you can change.
The oscilloscope stores these settings until you change them.
Turning off the oscilloscope does not erase these settings.
Menu
Settings Comments
Address 0 ... 30 Sets oscilloscope GPIB bus address
Bus Connection Talk-listen, Off-bus Select Talk-listen to turn on oscillo-
scope GPIB bus communications.
Select Off-bus to turn off oscillo-
scope GPIB bus communications.
