Appendix C: Remote Display
You can connect a remote display to the VGA connector on the rear panel.
Table A–3 on page A–3 gives the part number of a properly shielded cable that is
commercially available.
NOTE. Both the red and blue signal lines are grounded. This configuration
results in a green display on a color monitor.
