Tutorial
2–26
TDS 420A, TDS 430A, TDS 460A & TDS 510A User Manual
Example 4: Saving Setups
The digitizing oscilloscope can save its control settings and recall them later to
quickly re-establish the previously saved state. Do the following tasks to learn
how to save, and then recall, a setup.
First, you need to create an instrument setup you want to save. Perform the
following steps to create and save a setup that is complex enough that you might
prefer not to go through all these steps each time you want that display:
1. If you are not continuing from the previous example, follow the instructions
on page 2–11 under the heading Setting Up for the Examples.
2. Press SETUP
➞ Recall Factory Setup (main) ➞ OK Confirm Factory
Init
(side).
3. Press
➞ AUTOSET.
4. Press MEASURE
➞ Select Measrmnt (main) ➞ Frequency (side). (Press
the –more– side menu item if the Frequency selection does not appear in
the side menu.)
5. Press CH 2
➞ CLEAR MENU.
To save the setup, do the following steps:
6. Press SETUP ➞ Save Current Setup (main) to display the Setup main
menu (see Figure 2–18).
Save a Setup
