Tektronix TDS 420A Programmer's Manual

Command Groups
TDS Family Oscilloscope Programmer Manual
2–25
Table 2–16: Measurement Commands (Cont.)
Header Description
MEASUrement:IMMed:DELay:
DIREction
Search direction to use for delay measure-
ments
MEASUrement:IMMed:DELay:EDGE1 Which waveform edge to use for delay
measurements
MEASUrement:IMMed:DELay:EDGE2 Which waveform edge to use for delay
measurements
MEASUrement:IMMed:SOURCE[1] Channel to take measurement from
MEASUrement:IMMed:SOURCE2 Second channel to take measurement from
(delay or “to” channel)
MEASUrement:IMMed:TYPe The measurement to be taken
MEASUrement:IMMed:UNITS? Return measurement units
MEASUrement:IMMed:VALue? Return measurement result
MEASUrement:MEAS<x>? Return parameters on measurement
MEASUrement:MEAS<x>:COUNt?
(TDS 500C & 700C)
Returns the number of values accumulated for
this measurement since the last statistical
reset
MEASUrement:MEAS<x>:DELay? Return delay measurement parameters
MEASUrement:MEAS<x>:DELay:
DIRection
Search direction to use for delay measure-
ments
MEASUrement:MEAS<x>:DELay:EDGE1 Which waveform edge to use for delay
measurements
MEASUrement:MEAS<x>:DELay:EDGE2 Which waveform edge to use for delay
measurements
MEASUrement:MEAS<x>:MAXimum?
(TDS 500C & 700C)
Returns the maximum value found for this
measurement since the last statistical reset
MEASUrement:MEAS<x>:MEAN?
(TDS 500C & 700C)
Returns the mean value accumulated for this
measurement since the last statistical reset.
MEASUrement:MEAS<x>:MINImum?
(TDS 500C & 700C)
Returns the minimum value found for this
measurement since the last statistical test
MEASUrement:MEAS<x>:SOURCE[1] Channel (or histogram with TDS 500C &
700C) to take measurement from
MEASUrement:MEAS<x>:SOURCE2 Second channel (or histogram with TDS 500C
& 700C) to take measurement from (delay or
“to” channel)
MEASUrement:MEAS<x>:STATE Turn measurement display on or off
MEASUrement:MEAS<x>:STDdev?
(TDS 500C & 700C)
Returns the standard deviation of values
accumulated for this measurement since the
last statistical reset
