Tektronix TDS 420A Programmer's Manual

Command Groups
2–30
TDS Family Oscilloscope Programmer Manual
Table 2–21: Trigger Commands
Header Description
TRIGger Force trigger event; Return parameters
TRIGger:DELay Delay trigger level to 50%
TRIGger:DELay:BY Delay by time or events
TRIGger:DELay:EDGE? Return delay trigger parameters
TRIGger:DELay:EDGE:COUPling Delay trigger coupling
TRIGger:DELay:EDGE:SLOpe Delay trigger slope
TRIGger:DELay:EDGE:SOUrce Delay trigger source
TRIGger:DELay:EVENTS? Return delay trigger event parameters
TRIGger:DELay:EVENTS:COUNt Delay by events count
TRIGger:DELay:LEVel Delay trigger level
TRIGger:DELay:TIMe Time for delay by time
TRIGger:DELay:TYPe Delay trigger, edge
TRIGger:MAIn Main trigger level to 50%
TRIGger:MAIn:COMMunication:
AMI:PULSEForm (TDS 500C & 700C)
AMI pulse form setting (an Eye Diagram, an
Isolated +1, or an Isolated –1)
TRIGger:MAIn:COMMunication:
AMI:THReshold:HIGH (TDS 500C & 700C)
AMI threshold high level
TRIGger:MAIn:COMMunication:AMI:
THReshold:LOW (TDS 500C & 700C)
AMI threshold low level
TRIGger:MAIn:COMMunication:
BITRate (TDS 500C & 700C)
Communication trigger bit rate
TRIGger:MAIn:COMMunication:CMI:
PULSEForm (TDS 500C & 700C)
CMI pulse form
TRIGger:MAIn:COMMunication:CODe
(TDS 500C & 700C)
Select which line code the comm trigger
should expect on the incoming signal
TRIGger:MAIn:COMMunication:NRZ:
PULSEForm (TDS 500C & 700C)
NRZ pulse form
TRIGger:MAIn:COMMunication:SOUrce
(TDS 500C & 700C)
Communication trigger source channel
TRIGger:MAIn:COMMunication:
STANdard (TDS 500C & 700C)
Communication trigger standard which
identifies the code and bit rate
TRIGger:MAIn:EDGE? Return main edge trigger parameters
TRIGger:MAIn:EDGE:COUPling Main trigger coupling
TRIGger:MAIn:EDGE:SLOpe Main trigger slope
TRIGger:MAIn:EDGE:SOUrce Main trigger source
TRIGger:MAIn:HOLDOff? Return main trigger holdoff value
