Preface
x
TDS1000/2000-Series Digital Oscilloscope User Manual
Hyperlinks
Most of the help topics contain phrases marked with angle bra ckets,
such as <Autoset>. These are links to other topics. Turn the HELP
SCROLL knob to move the highlight from one link to another. Push
the Show Topic option button to display the topic corresponding to
the highlighted link. Push the Back option button t o return to the
previous topic.
Index
Push the front--pane l HEL P button, then push the Index option
button. Push the Page Up or Page Down option buttons until you find
the index page that contains the topic you want to view. Turn the
HELP SCROLL knob to highlight a help topic. Push the Show Topic
option button to display the topic.
NOTE. Push the Exit option button or any menu button to remove the
Help text from the screen and return to displaying waveforms.

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
