Reference
TDS1000/2000-Series Digital Oscilloscope User Manual
113
NOTE. The oscilloscope vertical response rolls off slowly above its
bandwidth (60 MHz, 100 MHz, or 200 MHz, depending on the model,
or 20 MHz when the Bandwidth Limit option is set t o On). Therefore,
the FFT spectrum can show valid frequency information higher than
the oscilloscope bandwidth. However, the magnitude information
near or above the bandwidth will not be accurate.
Knobs
VERTICAL POSITION Knobs. Use the VERTICAL POSITION knobs t o
move the channel waveforms up or down on the screen.
VOLTS/DIV Knobs. Use the VOLTS/DIV knobs to control how the
oscilloscope amplifies or attenuates the source signal of channel
waveforms. When you turn a VOLTS/DIV knob, the oscilloscope
increases or decreases the vertical size of the waveform on the screen
with respect to the ground leve l.
Key Points
GND Coupling. Use GND coupling to display a zero-vol t waveform.
Internally, the channel input is connected to a zero-volt reference
level.
Fine Resolution. The vertical scale re adout displays the actual
Volts/Div setting while in the fine resolution setting. Changing the
setting to coarse does not change the vertical scale until the
VOLT S/DIV control is adjusted.
