Tektronix TDS1002 User Manual

Reference
114
TDS1000/2000-Series Digital Oscilloscope User Manual
U in Level and Delta Readouts. Vertical sensitivity should match on
waveforms used for math operations. If the y do not match, and you
use cursors to measure the waveform result of a math operation, a U
displays that represents unknown units or scaling.
Remove Waveform. To remove a waveform from the display, push the
menu button for the channel to display its vertical menu. Push the
menu button again to remove the waveform.
NOTE. You do not hav e t o display a channel waveform to use it as a
trigger source or for math operations.

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
