Tektronix TDS1002 User Manual

Preface
xii
TDS1000/2000-Series Digital Oscilloscope User Manual
Product End-of-Life Handling
Components that Contain Mercury. The cold cathode fluorescent tube
located in the liquid crystal display backlight contains trace amounts
of mercury. When you are ready to reclaim the instrument, you must
properly transfer it according to local regulations concerning
mercury-containing equipme nt or ship the instrument to the
Tektronix Recycling Operati ons (RAMS). You can contact Tektronix
for the RAMS shipping address and instructions.

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
