Tektronix TDS1002 User Manual

Understanding Oscilloscope Functions
14
TDS1000/2000-Series Digital Oscilloscope User Manual
When you push the RUN/STOP or SINGLE SEQ buttons to start an
acquisition, the oscilloscope goes through the following steps:
1. Acquires enough data to fill the portion of the waveform record
to the left of the trigger point. This is also called the pretrigger.
2. Continues to acquire data while waiting for the trigger condition
to occur.
3. Detects the trigger condition.
4. Continues to acquire data until the waveform record is full.
5. Displays the newly-acquired waveform.
NOTE. For Edge and Pulse triggers, the oscilloscope counts the rate
at which trigger events occur to determine trigger frequency and
displays the frequency in the lower right corner of the screen.
Source
You can use the Trigger Source options to select the signal t hat the
oscilloscope uses as a trigger. The source can be any signal
connected to a c hannel BNC, to the EXT TRIG BNC or the AC
power line (availa ble only with Edge triggers).

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
