Tektronix TDS1002 User Manual

Application Examples
44
TDS1000/2000-Series Digital Oscilloscope User Manual
3. Push the Type option button and select Freq.
The Va l ue readout displays the measurement and updates.
NOTE. If a question mark (?) displays in the Value readout, turn the
VOLTS/DIV knob for the appropriate channel to increase the
sensitivity or change the SEC/DIV setting.
4. Push the Back option button.
5. Push the second option button from the t op; the Measure 2 Menu
appears.
6. Push the Type option button and select Period.
The Va l ue readout displays the measurement and updates.
7. Push the Back option button.
8. Push the middle option button; the Measure 3 Menu a ppears.
9. Push the Type option button and select Pk-Pk.
The Va l ue readout displays the measurement and updates.
10. Push the Back option button.

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
