Reference
84
TDS1000/2000-Series Digital Oscilloscope User Manual
Cursors
Push the CURSOR button to display the measurement cursors and
Cursor Menu.
Options Settings Comments
Type*
Voltage
Time
Off
Select and display the measurement
cursors; Voltage measures amplitude and
Time measures time and frequency
Source CH1
CH2
CH3**
CH4**
MATH
REFA
REFB
REFC **
REFD **
Choose the waveform on which to take
the cursor measurements
The readouts display this measurement.
Delta Displays the difference (delta) between
the cursors
Cursor 1 Displays cursor 1 location (time is
referenced to the trigger position, voltage
is referenced to ground)
Cursor 2 Displays cursor 2 location (time is
referenced to the trigger position, voltage
is referenced to ground)
* For a Math FFT source, measures magnitude and frequency.
** Available only on 4-channel oscilloscopes.
