Tektronix TDS2014 User Manual

Reference
TDS1000/2000-Series Digital Oscilloscope User Manual
91
NOTE. You can push the horizontal option buttons to switch between
an entire waveform display and an enlarged, more detailed part of it.
The axis for vertical scale is the ground level. A readout near the top
right of the screen displays the current horizontal position in seconds.
An M indicates the Main time base and a W indicates the Wi ndow
time base. The oscilloscope also indicates horizontal position with an
arrow icon at the top of the gra ticule.
Knobs and Buttons
HORIZONTAL POSITION Knob. Use to control the position of the trigger
relative to the center of the screen.
SET TO ZERO Button. Use to set the horizontal position to zero.
SEC/DIV Knob (Horizontal Scale). Use to change the horizontal time
scale to magnify or compress the waveform.
Key Points
SEC/DIV. If waveform acquisition is stopped (using the RUN/STOP or
SINGLE SEQ button), the SEC/DIV control expands or compresses
the waveform.

Tektronix TDS2014 Specifications

General

Channels	4
Bandwidth	100 MHz
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Display	5.7 inch color LCD
Trigger Types	Edge, Video
Interface	USB
Input Impedance	1 MΩ
Power Requirements	100 to 240 V
