TDS1000/2000-Series Digital Oscilloscope User Manual
U in Level and Delta Readouts. Vertical sensitivity should match on
waveforms used for math operations. If the y do not match, and you
use cursors to measure the waveform result of a math operation, a U
displays that represents unknown units or scaling.
Remove Waveform. To remove a waveform from the display, push the
menu button for the channel to display its vertical menu. Push the
menu button again to remove the waveform.
NOTE. You do not hav e t o display a channel waveform to use it as a
trigger source or for math operations.

Tektronix TDS2014 Specifications

General

Channels	4
Bandwidth	100 MHz
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Display	5.7 inch color LCD
Trigger Types	Edge, Video
Interface	USB
Input Impedance	1 MΩ
Power Requirements	100 to 240 V
