Tektronix TDS2014 User Manual

Reference
TDS1000/2000-Series Digital Oscilloscope User Manual
89
NOTE. The oscilloscope can capture a waveform in normal YT mode
at any sampling rate. You can view the same waveform in XY mode.
To do so, stop the acquisition and change the di splay format to XY.
The controls operate as follows:
H The channel 1 VOLTS/DIV and VERTICAL POSITION controls
set the horizont al scale and position.
H The channel 2 VOLTS/DIV and VERTICAL POSITION controls
continue to set vertical scale a nd position.
The following functions do not work in XY display format:
H Reference or Math waveforms
H Cursors
H Autoset (resets display format to YT)
H Time base controls
H Trigger controls
Help
Push the HELP button to display the Help menu. The topics cover all
the menu options and controls of the oscilloscope. For more
information on the Help system, refer to page ix.

Tektronix TDS2014 Specifications

General

Channels	4
Bandwidth	100 MHz
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Display	5.7 inch color LCD
Trigger Types	Edge, Video
Interface	USB
Input Impedance	1 MΩ
Power Requirements	100 to 240 V
