Tektronix TDS2014 User Manual

Reference
78
TDS1000/2000-Series Digital Oscilloscope User Manual
Acquisition mode SINGLE SEQ button
Sample, Peak Detect Sequence is complete when one acquisition is acquired
Average Sequence is complete when the defined number of
acquisitions is reached (refer to page 74)
Scan Mode Display. You can use the Horizontal Scan acquisition mode
(also called Roll mode) to continuously moni tor signals that change
slowly. The oscilloscope displays waveform updates from the left to
the right of the screen and erases old points as it displays new points.
A moving, one-division-wide blank section of the screen sepa rates
the new waveform points from the old.
The oscilloscope changes to the Scan acquisition mode when you
turn the SEC/DIV knob to 100 ms/div or slower, and select the Auto
Mode option in t he TR IGGER Menu.
To disable Scan mode, push the TRIG MENU button and set the
Mode option to Norma l.
Stopping the Acquisition. While the acquisition is running, the
waveform display is live. Stopping t he acquisition (when you push
the RUN/STOP button) freezes the display. In either mode, the
waveform display can be sca led or positioned with the vertical a nd
horizontal controls.

Tektronix TDS2014 Specifications

General

Channels	4
Bandwidth	100 MHz
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Display	5.7 inch color LCD
Trigger Types	Edge, Video
Interface	USB
Input Impedance	1 MΩ
Power Requirements	100 to 240 V
