Vertical Controls
TDS3000B Serie s User Manual
3-87
Scaling and Positioning a Reference Waveform You can position and
scale a reference waveform independenty from all other di splaye d
waveforms. Select the reference waveform and then adjust it with a
vertical or horizontal POSITION or SCALE control. You can do this
whether acquisition is running or is stopped.
If a reference waveform i s selected, scaling and repositioning of the
reference waveform operates the same way whether zoom is turned
on or off.
Gray-Scale Restriction. Reference waveforms are always saved from
the most current acquisition and do not contain any gray-scale
information.
NOTE. The TDS3AAM Advanced Analysis application module adds
new math features, including arbitrary math expressions, DPO
(grayscale) math waveforms, and FFT analysis.
