Tektronix TDS3034B User Manual

Appendix A: Specifications
A-8
TDS3000B Serie s User Manual
Specifications (cont.)
Trigger
Video trigger sensitivity,
i
l
Triggers on negative sync of NTSC, PAL, or SECAM signal
g
g
y
,
typical
Source Sensitivity
Any channel 0.6 to 2.5 divisions of video
sync tip
External trigger 150 mV to 625 mV of video
sync tip
External/10 trigger 1.5 V to 6.25 V of video sync
tip
B Trigger Trigger After Time Trigger After B Events
Range 13.2 ns to 50 s 1 event to 9,999,999 events
Minimum time
between arm and
trigger, typical
5ns from the end of the time
period and the B trigger event
5 ns between the A trigger
event and the first B trigger
event
Minimum Pulse
Width, typical
— B event width, 2 ns
Maximum Fre-
quency, typical
— B event frequency, 250 MHz
