Tektronix TDS5000B Series

Installation Instructions
TDS5000B Series (Option 1R) Rackmount Kit
11
Right-side
cover
Left-side
cover
Top cover
Carrying handle
CD-drive trim
Accessory tray door
or printer cover
VGA panel
Accessory tray or printer
(not supported SN B030000 & above)
Bottom
cosmetic cover
Line cord
Feet/line cord
holders (2)
T-15 Torx screw (2)
T-15 Torx
screw (2)
T-15 Torx screw (2)
T-15 Torx screw (2)
T-15 Torx
screw (2)
T-15 Torx screw (2)
Accessory
pouch bracket
Figure 4: Strip instrument for conversion
