Installation Instructions
12
TDS5000B Series (Option 1R) Rackmount Kit
Install
Equipment Required: Torque driver with T-15 tip (Items 5 and 3).
This section describes mounting the rackmount parts to the instrument.
1. Remove the front section of each of the two tracks. See Figure 5.
Remove this section
from each track.
Figure 5: Prepare tracks for mounting
To Next Page
