Tektronix THDP0100 Installation And Safety Instructions

Standard Accessories
THDP0100 probe standard accessory derating table
Combined probe and accessory common-mode voltage
and input voltage-to-earth ratings
Accessory THDP0100 THDP0200
1
TMDP0200
1
Extender leads
(196-3523-xx)
2300 V CAT I
1000 V CAT III
1000 V CAT II
600 V CAT III
550 V CAT I
300 V CAT III
Test probes
(TATP)
1000 V CAT I
1000 V CAT II
1000 V CAT II
600 V CAT II
550 V CAT I
300 V CAT II
Small hook tips
(TASH)
2300 V CAT I
1000 V CAT II
1000 V CAT II
600 V CAT II
550 V CAT I
300 V CAT II
Large hook tips
(TALH)
2300 V CAT I
1000 V CAT II
1000 V CAT II
600 V CAT II
550 V CAT I
300 V CAT II
1
The THDP0200 and TMDP0200 probes can also be used with the THDP0100 standard
accessories, but only at the reduced voltage levels listed in this table.
WARNING.
To avoid risk of electric shock or fire, when using the THDP0100 test
probe or hook tip accessories with the THDP0200 and TMDP0200 probes, do not
use on circuits above 1000 V.
To avoid risk of electric shock or fire, do not use the THDP0100 test probe or hook
tip accessories on CAT III or CAT IV circuits. Refer to the d erating table above.
17
