Tektronix TLA7000 Series User Manual

Specifications
Specification
s
This section provides the warranted and mechanical specifi cations for the TLA5000B Series Logic Analyzers, TLA7000
Series Logic Analyzers, TLA 7Bxx, TLA7ACx, and TLA7N4 Series Logic Analyzer. All specifications (marked with the.
symbol) are guaranteed and can be checked directly or indirectly at your nearest Tektronix location or by following the
procedures described in individual service manuals or performance verification documents. Typical specifications are
provided for your convenience but are not guaranteed.
The performance limits in these specifications are valid under the following conditions:
The instrument must be in an environment with temperature, altitude, humidity, and vibration within the operating limits
described in these specifications.
Logic analyzer modules must be installed in a logic analyzer mainframe.
The instrument must have had a warm-up period of at least 30 m inutes.
The instrument must have been calibrated and adjusted at an ambient temperature between +20 °C and +30 °C.
Atmospheric characteristics
Characteristic Description
Temperature:
Operating and nonoperating
Operating (no media in floppy disk drive or DVD drive):
+5 °C to +50 °C, 15 °C/hr maximum gradient, noncondensing (derated 1 °C
per 305 m (1000 ft) above 1524 m (5000 ft) altitude)
12
Nonoperating (no media in floppy disk drive or DVD drive):
–20 °C to +60 °C, 15 °C/hr maximum gradient, noncondensing
Relative H u m idity :
Operating and nonoperating
Operating (no media in floppy disk drive or DVD drive):
20% to 80% relative humidity, noncondensing. Maximum wet bulb temperature:
+29 °C (derates relative humidity to approximately 22% at +50 °C)
34
Nonoperating (no media in floppy disk drive or DVD drive):
8% to 80% relative humidity, noncondensing. Maximum wet bulb temperature:
+29 °C (derates relative humidity to approximately 22% at +50 °C)
5
Altitude:
Operating and nonoperating
Operating:
To 3000 m (9843 ft), (derated 1 °C per 305 m (1000 ft) above 1524 m (5000 ft)
altitude
Nonoperating:
12190 m (40,000 ft)
1
TLA7Bxx and TLA7ACx series module operating temperature is +40 °C maximum.
2
TLA7012 operating temperature is 45 °C maximum due to the CD-RW DVD drive.
3
TLA
7Bxx series module relative humidity derates to approximately 57% at +40 °C.
4
TLA7Bxx and TLA7ACx series module operating humidity is 5% to 90% up to +30 °C, 75% from +30 to +40 °C, noncondensing. Maximum
wet-bulb temperature is +29.4 °C.
5
TLA7Bxx and TLA7ACx series module nonoperating humidity is 5% to 90% limited by a wet bulb temperature of +40 °C.
42 TLA Q uick Start User M anual
