Tektronix TLA7000 Series User Manual

Specifications
Product Features
Characteristi
c
Description
CLK10 Frequency (mainframes)
10 MHz ±100 PPM
TLA7012 mainframe slots
4
TLA7016 mainframe slots
13
MagniVu memory depth (samples per
channel)
2048 for TLA7N4 modules
16,000 for TLA7ACx modules and TLA5000B instruments
128,000 for TLA7Bxx modules
MagniVu sampling period
125 ps for TLA7ACx m odules and TLA5000B instruments
500 ps for TLA7N4 modules
20 ps for TLA7Bxx modules
Data is asynchronously sampled and stored in a separate high-resolution memory.
The storage speed may be changed (by software) to 250 ps, 500 ps, or 1000 ps,
so that the MagniVu memory covers more time at a lower resolution.
Number of channels
TLA5201B 32 data and 2 clock
TLA5202B, TLA7AC2, TLA7BB2
64 data and 4 clock
TLA5203B
96 data, 4 clock, and 2 qualifier
TLA5204B, TLA7N4
128 data, 4 clock, and 4 qualifier
TLA7AC3, TLA7B B3 96 data and 6 clock/qualifier
TLA7AC4, TLA7BB4, TLA7BC4 128 data and 8 clock/qualifier
Acquisition memory depth
TLA5000B
2 M or optionally 8 M or 32 M samples (PowerFlex options)
TLA7ACx, TLA7Bxx
64 M per channel, maximum
TLA7N4
64 K or 256 K or 1 M or 4 M samples (PowerFlex options)
TLA Quick Start User Manual 43

Tektronix TLA7000 Series Specifications
