Tektronix TLA7000 Series User Manual

Specifications
Mechanical characteristics
Characteristi
c
Description
TLA5000B dimensions
Height
284.44 mm (11.200 in)
Width
288.29 mm (11.350 in)
Length
444.5 mm (17.500 in)
TLA7012 dimensions
Height (with feet) 29.46 cm (11.6 in)
Width
45.08 cm (17.75 in)
Depth
45.97 cm (18.1 in)
TLA7016 d
imensions
Height (
with feet)
34.67 cm
(13.7 in)
Width
42.42 c
m (16.7 in)
Depth
67.31 c
m (26.5 in)
TLA7B
xx, TLA7ACx, and TLA7N4 dimensions
Height
262 mm
(10.32 in)
Width
61 mm
(2.39 in) with merge connector in the recessed position
Width increases by 10.41 mm (0.41 in) with merge connector in the extended
position.
Length
373 mm (14.7 in)
Weight (TLA5000B and mainframes include empty accessory pouch, slot covers, and front cover)
TLA715
13.9 kg (30 lbs 12 oz)
TLA721 and TLA7XM
26.7 kg (58 lbs 11 oz), with benchtop controller
TLA7012
18.45 kg (40 lbs 12 oz)
TLA7016
24 kg (52 lbs 14 oz)
TLA5201B
11.8kg(25lb15oz)
TLA5202B
11.85kg(26lb2oz)
TLA5203B
11.9 kg (26 lb 4 oz)
TLA5204B
12kg(26lb7oz)
TLA7AC2, TLA 7BB2 2.282 kg (5 lb 0.5 oz)
TLA7AC3, TLA 7BB3 2.381 kg (5 lb 4 oz)
TLA7AC4, TLA7BB4, TLA7BC4 2.438 kg (5 lb 6 oz)
TLA7N4
2.55 kg (5 lbs 10 oz)
46 TLA Q uick Start User M anual
