Getting Acquain
ted With Your Instrument
Selecting S ignal Inputs
You c an connect SDI (Serial Digital Interface) signals and select them for display. Depending on your instrument model
and the options installed on it, you can also connect High Definition (HD) component signals and Standard Definition
(SD) component signals.
To Select an SDI Input
1. Connect digital component video signals
to the SDI A and SDI B inputs on the
rear panel.
HD (WFM5000
series): The
instrument automatically detects
whether input is HD or SD.
SD (WFM4000 series): Connect SD
signal onl
y.
2. Press the Input button corresponding
to the input that you want (SDI Input A
shown).
3. Select a d
isplay to view the input.
Setting 4-Tile and Full-Tile Modes
You can
access the 4-Tile and Full-Tile functions from the MAIN button. 4-Tile mode allows you to view four displays at
the same time. E ach display will appear in one of four tiles on the display screen. Full-tile mode allows you to view the
display in tile 1 at full screen.
When you press the MAIN button, a pop-up menu will appear allowing you access to the 4-Tile and Full-Tile settings. To set
up the
instrument to view four tiles simultaneously, perform the following procedure.
1. Pres
s and hold the MAIN button to view
the pop-up menu.
2. Press the up or down arrow key to
navigate to Tile Display and then press
the r
ight arrow key to highlight 4-Tile.
This will select 4-Tile mode and the
screen will display four separate tiles.
16 WFM4000 and WFM5000 Waveform Monitors User Manual
