The decoded ancillary data includes the following:
DID - Data Identifier of the requested packet; permissible values range from 1 to 0xFF (255) inclusive.
Type - Type of the ANC Data packet. For ARIB TR-B.22, this is always a Type 2 packet (DID less than 0x80), as defined
by SMPTE 291M.
The actual value (with parity bits added) is displayed in parentheses.
SDID - Seconda
ry Data Identifier of the requested packet; permissible values range from 0 through 0xFF (255) inclusive.
This field only appears when a Type 2 packet is selected (see above). The actual value (with parity bits added) is
displayed in parentheses.
DC - D ata Count word of the acquired packet. The number of User Data words is displayed in decimal. The actual value
(with parit
y bits added) is displayed in parenthesis, in hexadecimal.
Field - The fi
eld of the video from which the packet was acquired. For progressive formats, 1 is displayed.
Line - T he li
ne of the video (within the field) from which the packet was acquired.
Stream - F o
r HD (SMPTE 292M), indicates whether the ancillary packet was acquired from the Y or C data s treams.
For SD, N/A is displayed.
Status - Indicates whether packet(s) of the desired type are present in the video; also indicates Checksum or CRC errors.
Checksum - Indicates the checksum word that was r ecovered from the acquired packet.
Should be - Indicates the checksum work computed by the instrument, based on the packet’s data.
Format - Indicates the name of the ancillary data type or standard.
User Data Words - Contains the payload of the ancillary packet, displayed in hexadecimal. All 10 bits are displayed.
