Tektronix WFM7020 User Manual

Monitoring Audi
o
Checking Surround S ound
Your instrument can also display the surround sound listening environment. The following procedures you will help you
get started.
To Check Surround Sound
1. Open the audi
o display in one tile and
select the input containing the surround
audio. (See page 89.)
2. Select Aux Display and then select
Surround S
ound Display.PressSEL
or the right-arrow key to turn the phase
display on.
3. Set the Audio Input to match the signal
that you a
re checking.
NOTE. If you want the level bars labeled
with their surround sound channel names
instead o
f channel numbers, select Srnd
(Surround) when you configure the audio
inputs. (See page 100.)
You can also set the Dolby Listening mode.
(See pag
e 103, Monitor Dolby-Based
Surround Sound.)
4. Set the surround Dominance indicator
to ON or OFF.
96 Waveform Monitors Quick Start User Manual
